HYC170
Rack & Pinion Module
HYC170 rack & pinion module with repeatability ±0.02/300 mm, max speed 650~2200 mm/s, payload up to 85~250 kg, stroke 900~5500/100Pitch mm, designed for ultra-long stroke heavy-load applications.
Specifications
| Performance | |
|---|---|
| Repeatability | ±0.02/300 mm |
| Applications | |
|---|---|
| Material Handling & Logistics Automation | Warehouse Palletizing Robots: High-speed stacking of heavy cargo (e.g., machinery, automotive parts) up to 250kg, optimized for long-stroke efficiency (5500mm) in large distribution centers . |
| Heavy Machinery & Construction Equipment | Wind Turbine Assembly: Positioning rotor blades and gearboxes under 40kg vertical loads, with 2M rack rigidity for vibration-free operation . |
| Stage & Entertainment Rigging | Concert/Theater Motion Systems: Smooth movement of heavy lighting, screens, or stage sets (250kg+) with 5500mm travel flexibility and low-noise servo performance . |
| Automotive Production Lines | Chassis/Engine Transfer: High-speed transport of heavy automotive components in assembly plants, supporting ± 0.02mm repeatability for alignment-critical processes . |
Technical Downloads
Customization
Custom solutions based on speed and load requirements
Anti-rust treatment, high/low temperature, explosion-proof and vacuum compatibility
Bellows dust covers with expandable protection accessories
Multi-axis synchronization and custom program development
Request a Quote
